Specifications
| Mechanism | Stepper motor |
| Syringe type | 5,10,20,30,50/60ml |
| Infusion Modes | Rate mode; Time mode; Body weight mode； Intermittent administration mode. |
| Flow rate range | 5ml: 0.1~150ml/h; 10ml: 0.1~300ml/h; 20ml: 0.1~600ml/h; 30ml: 0.1~900ml/h; 50/60ml: 0.1~1500ml/h. |
| VTBI | 0.1~999.9 ml, the increment is 0.1 ml; 1000-9999ml, increment is 1ml |
| Accumulated volume | 0.1-9999ml |
| Increments | 0.1ml/h(0.1-999.9ml/h) 1ml/h(1000-1500ml/h) |
| Accuracy (± %) | ≤ ±2% |
| KVO | 0.1~5.0ml/h, adjustable |
| Bolus rate | 0.1~1500ml/h |
| Purge rate | 150-800ml/h |
| Occlusion level | 4 levels |
| Occlusion pressure range | Low: 300±125 mmHg (40kPa); Medium: 525±125 mmHg (70kPa); High: 900±180 mmHg (120 kPa). |
