| Pump Specifications | |
| Mechanism | Peristaltic |
| IV set type | General |
| Infusion Modes | Rate mode; Time mode; Body weight mode; Sequential mode. |
| Flow rate range | 0.1~1500ml/h |
| VTBI | 0.1~999.9 ml, the increment is 0.1 ml;
1000-9999ml, increment is 1ml |
| Accumulated volume | 0.1-9999ml |
| Increments | 0.1ml/h(0.1-999.9ml/h) 1ml/h(1000-1500ml/h) |
| Accuracy (± %) | ≤±5% |
| KVO | 0.1-5.0ml/h, adjustable, step 0.1ml/h |
| Bolus rate | 0.10-1500ml/h |
| Purge rate | 800ml/h |
| Occlusion level | 3 levels |
| Occlusion pressure range | Low 150±125 mmHg (20kPa); Medium 525±125 mmHg (70kPa); High 900±180 mmHg (120 kPa) |
| Air bubble level | 5 levels |
| Air bubble size | Single bubble detection: 50, 100, 250, 500, 800l μl Accumulated bubble detection: 0.1-4.0ml/h, adjustable |
| Display | |
| Screen | 3.0” LCD monochrome screen, 240 x 128 pixels |
| Display info. | Flow rate, current infusion,VTBI, total volume, IV set brand, pressure limit, battery capacity, drugs, remaining time, alarms |
| Functions | |
| change flow rate during infusion | ● |
| Last configuration memory | ● |
| Front-panel lockout | ● |
| Standby | ● |
| Pause | ● |
| Silence | ● |
| Drip rate function | ● (optional) |
| Drug library | |
| Drug Library capacity | 200 |
| History records | |
| Records quantity | 1500 |
| Records type | Parameter changing; Turn on/off; Start/stop infusion; Bolus; Alarm; Silence. |
| Records stored time limit | First in first out |
| Records transmitted to PC | ● |
| Event log | ● |
| Alarm | |
| Real-time alarm display | ● |
| Auto self-test system | ● |
| Infusion finish | ● |
| Infusion near end | ● |
| IV set disengaged | ● |
| Occlusion | ● |
| Air in line | ● |
| Flow error | ● |
| Door open | ● |
| System malfunction | ● |
| System abnormal | ● |
| Low battery | ● |
| Battery empty | ● |
| Reminder | ● |
| Standby end | ● |
| No AC Power | ● |
| Interface | |
| Data port | ● RS232 |
| Nurse call jack | ● |
| DC input | ● |
| Battery | |
| Battery type | Lithium |
| Battery operating time | >4 hours@25ml/h |
| Battery recharge time | ≤6 hours@100% |
