| Pumping Mechanism |
Curvilinear peristaltic |
| IV Set |
Compatible with IV sets of any standard |
| Flow Rate |
1-1200 ml/h (in 0.1 ml/h increments) |
| Purge, Bolus |
600-1200 ml/h (in 1 ml/h increments)
Purge when the pump stops, bolus when the pump starts |
| Accuracy |
±3% |
| VTBI |
1-20000 ml |
| Infusion Mode |
ml/h, drop/min, time-based |
| KVO Rate |
1-5 ml/h |
|
Alarms |
Occlusion, air-in-line, door open, end program, low battery, end battery, AC power off, motor malfunction, system malfunction, standby |
|
Additional Features |
Real-time infused volume, automatic power switching, mute key, purge, bolus, system memory, key locker |
| Occlusion Sensitivity |
High, medium, low |
| History Log |
30 days |
| Air-in-line Detection |
Ultrasonic detector |
| W wireless Management |
Optional |
| Vehicle Power (Ambulance) |
12 V |
| Power Supply,AC |
100-230 V (optional), 50-60 Hz, ≤30 VA |
| Battery |
12 V, rechargeable |
| Battery Life |
8 hours at 25 ml/h |
| Working Temperature |
10-30℃ |
| Relative Humidity |
30-75% |
| Atmospheric Pressure |
860-1060 hPa |
| Size |
150*125*60 mm |
| Weight |
1.7 kg |
| Safety Classification |
Class Ⅱ, type CF |
