| Throughput |
140 tests/hour |
| Assay method |
End point, kinetic, fixed time, bichromatic, multi-standard, two-step end-point and other assay methodologies |
| Calibration type |
Linear or nonlinear with 1 – 6 standard calibration levels |
| System calibration |
Deduction of water blank/reagent blank |
| Sample tray |
64 available positions for samples, calibration, benchmark and quality control |
| Sample volume |
1 ~ 100 ul,1 ul/step |
| Sample probe |
With liquid detection and crash-protection function |
| Reaction tray |
96 reaction cuvettes |
| Flow cell |
32 ul, automatically washing |
| Optical system |
6 V/10 W halogen lamp
7 high quality narrow band wavelength filters and 2 free positions for additional filters.
Photometric measurement range: 0 – 3.0 absorbance |
| Dilution |
1000 ul,1.0 ul/step |
| Operating temperature |
37 °C + 0.1 °C |
| Storage capacity |
Stores over 200 programs and one million test results |
| External devices (on request) |
Pentium IV PC, printer, monitor |
| Power supply |
AC 110/220 V ± 10 %, 50/60 Hz ± 1 Hz |
| Connectivity |
USB 2.0 |
