Specifications
● Flow rate: O2 0.05 ~ 1 L/min; 1 ~ 10 L/min N2O 0.05 ~ 1 L/min; 1 ~ 10 L/min
Air 0.2 ~ 1 L/min; 1 ~ 12 L/min ORC O2 ≥ 25%
● O2 flush: 35 ~ 75 L/min
● Insufficient oxygen alarm and automatic N2O calibration function:
When O2 level is ≤ 0.2 Mpa, audible alarm sounds and lasts for at least 7 seconds
When O2 level is ≤ 0.14 Mpa, N2O flow decreases correspondingly
When O2 level is ≤ 0.04 Mpa, N2O flow is cut off completely
● Integrated breathing circuit system, APL adjustment range: 0.5 ~ 7 kPa
● CO2 absorber capacity: 1.6 L
● Vaporizer ambient temperature: 15 ~ 35 °C
● Input flow: 0.25 ~ 15 L/min
● Output back pressure: -10 kPa ~ 20 kPa
● Output concentration: 0.2 % ~ 5% (± 0.2 %) (Vol %)
● Ventilation frequency: 6 ~ 40 bpm
● Tidal volume; adult: 100 ~ 1100 ml Infant: 30 ~ 150 ml
● I:E: ratio 1:1 ~ 1:9.9 (adjustable)
● Operating Modes: Pneumatically driven & electronically controlled, closed, semi-closed and semi-open
● Anesthesia Ventilator: Built-in high visibility, wide angle LED alphanumeric data display
● Standard integrated metallic modular respiratory circuit; completely solves the problem of gas sealing under high temperature disinfection, easy to clean and disinfect
● High precision two tube flowmeter, fitted with interlocking oxygen-nitrous oxide supply, guarantees oxygen output is never lower than 21%
● Power Failure Support Functions: Automatically converts to backup power mode during AC power outages
● Fully metallic frame, precise construction, elegant design, equipped with automated self-checking function during startup and an automatic self-calibrating sensor
● Alarms: Audible and/or visual alarms for tidal volume, airway pressure, power failure, oxygen failure and other alarms
● Operating Modes: Pneumatically driven & electronically controlled, closed, semi-closed and semi-open
● Anesthesia Ventilator: Built-in high visibility, wide angle LED alphanumeric data display
● Standard integrated metallic modular respiratory circuit; completely solves the problem of gas sealing under high temperature disinfection, easy to clean and disinfect
● High precision two tube flowmeter, fitted with interlocking oxygen-nitrous oxide supply, guarantees oxygen output is never lower than 21%
● Power Failure Support Functions: Automatically converts to backup power mode during AC power outages
● Fully metallic frame, precise construction, elegant design, equipped with automated self-checking function during startup and an automatic self-calibrating sensor
● Alarms: Audible and/or visual alarms for tidal volume, airway pressure, power failure, oxygen failure and other alarms
