Features:
● Five-step drum magnification for the eyepiece. The Sclera vein could be observed under the 40× magnification
● All the optical lenses are moistureproof, mildewproof, and anti-reflected tested
● Large spot diameter, slit length reach to 14mm, more comprehensive view of the eye condition
● Multi-coated optical glass technology, imaging is clear and bright, and the view field is wide
● Osram light bulbs, small heat, high brightness, spot uniformity
● Handrail design, user-friendly and convenient of patients
● Oversized joystick space, mobile base does not touch the hand
● All the joints can be connected by accessories with international standards
Specifications:
| Microscope | Microscope Type | Galilean stereoscopic microscope |
| Magnification selection | 5 steps by drum rotation | |
| Eyepiece | 12.5x | |
| Magnification Ratio
(Field of view ) |
6×（φ33mm）, 10×（φ22.5）, 16×（φ14mm）, 25×（φ8.8mm）, 40×（φ5.5mm） | |
| PD adjustment | 50mm ~ 82mm | |
| Diopter Adjustment | +7D ~ -7D | |
| Base | Side Shift | 110mm |
| Depth Shift | 90mm | |
| Height Shift | 30mm | |
| Chin rest | Height Shift | 80mm |
| Fixation Target | red LED | |
| Illumination System | Slit width | 0 ~ 14mm continuous (at 14mm，slit becomes a circle) |
| Slit height | 1 ~ 14mm continuous | |
| Slit angle
Slit Inclination |
0 ~ 1800 continuous
0, 50, 100 150, 200 Ф14mm , Ф10mm, Ф5mm , Ф3mm , Ф2mm , Ф1mm , Ф0.2mm , Ф1mm~Ф1-14mm continuous |
|
| Filter | Heat absorption ,Grey ,Red-Free ,Cobalt Blue | |
| Illumination bulb | 12V 50W halogen lamp | |
| Weight and size | G.W/N.W | 18kg/16kg |
| Main dimension | 690mm（L）× 440mm（W）× 420mm（H） |
