| Component |
Detail |
| Power Output |
25kW |
| Inverter Frequency |
40kHz |
| X-ray Tube |
Rotary anode, Dual-focus, Large focus: 1.3mm*1.3mm, |
| Small focus: 0.6 mm*0.6mm, Thermal capacity: 900kJ |
| Rotary Anode Speed |
3000rpm |
| Tube Current |
200mA |
| Tube Voltage |
40-125kV |
| mAs |
0.4-360mAs |
| Table Radiography |
Grid density: 103L/INCH; Grid ratio: 8:1; Focusing distance: 120cm ;Stationary type:15″×18″ (imported) |
| Bucky Stand Radiography |
Grid density: 103L/INCH; Grid ratio: 10:1; Focusing distance: 150cm; Stationary type: 18″×18″ (imported) |
| Power Supply |
380V 50Hz, Capacity: ≥30kVA |
| Operation Method |
Color LCD touchscreen graphical control console |
| 20 meters wireless remote exposure control |
| Configuration Characteristics |
| Table Size |
2000×760mm |
| Table Height |
≤700mm |
| Transverse Travel of Table |
±110mm (Electromagnetic brake) |
| Longitudinal Travel of Table |
±325mm (Electromagnetic brake) |
| Cassette Holder Grid Movement |
≥560mm (Cassette frame which can link with a column to take face film; not linkage with the column, to take angle film.) |
| X-ray Tube Rotation |
±90° (Electromagnetic brake) |
| Floor Stand Rotation |
360° (4×90°, Mechanical brake) |
| Axial Rotation |
0-35° (Mechanical brake) |
| SID |
420-1200mm(Electromagnetic brake) |
| Floor Stand Longitudinal Travel (along table) |
≥1350mm (Electromagnetic brake) |
| Beam Aperture Opening Duration |
Approx 30s |
| Film Size |
5″×7″-14″×17″ (Table radiography) |
| 5″×7″-17″×17″ (Bucky stand radiography) |
| Movement Range of Chest X-ray Frame |
560-1625mm |
