● Operating Modes: Pneumatically driven & electronically controlled, closed, semi-closed and semi-open
● Anesthesia Ventilator: Built-in 8.4 inch color TFT display, able to display Pressure-Time, Flow-Time, Pressure-Volume and Flow-Volume, displayed waveforms can be cycled instantly with a touch of a button
● Standard integrated metallic modular respiratory circuit; completely solves the problem of gas sealing under high temperature disinfection, easy to clean and disinfect
● Power Failure Support Functions: Automatically converts to backup power mode during AC power outages
● Equipped with electronic pressure differential flow sensor, imported respiratory control valve, stable and reliable, rapid response time
▅ Display: 8.4 inch TFT display
▅ Flowmeter Range: O2: 0.1-10L/min N2O: 0.1-10L/min Air: 0.1-10L/min
▅ Ventilation Mode: IPPV, SIPPV, VCV, IMV, SIMV, MANUAL, Standby
▅ Back-up Power Supply: At least 4 hours
▅ Tidal Volume: Adjustable range: 20-1500ml / Display range: 0-2000ml
▅ Respiratory Rate: 1-100bpm
▅ Inspiratory/Expiratory (I:E) Ratio: 8:1-1:10 (capable of inverse ratio ventilation
▅ PEEP Range: 0-20cmH2O (electronically controlled)
▅ Inspiratory Pressure Trigger Range: -10-10cmH2O (electronically controlled)
▅ Sigh: 1 sigh breath in every 80-120 breaths
▅ Inhaled Oxygen Concentration Monitor: 21-100%
▅ SIMV Rate: 1-20bpm
▄ Inspiratory Plateau: 0-1secpnd
▅ Vaporizer Concentration Ranges: 0-5%
▅ Vaporizer Slots: Double PA-I type slots
● Operating Modes: Pneumatically driven & electronically controlled, closed, semi-closed and semi-open
● Anesthesia Ventilator: Built-in high visibility, wide angle LED alphanumeric data display
● Standard integrated metallic modular respiratory circuit; completely solves the problem of gas sealing under high temperature disinfection, easy to clean and disinfect
● High precision two tube flowmeter, fitted with interlocking oxygen-nitrous oxide supply, guarantees oxygen output is never lower than 21%
● Power Failure Support Functions: Automatically converts to backup power mode during AC power outages
● Fully metallic frame, precise construction, elegant design, equipped with automated self-checking function during startup and an automatic self-calibrating sensor
● Alarms: Audible and/or visual alarms for tidal volume, airway pressure, power failure, oxygen failure and other alarms
